13: LPT library function reference Model 4200A-SCS Parameter Analyzer
13-160 4200A-901-01 Rev. C / February 2017
The pulse voltage low setting takes effect immediately during continuous pulse output. Otherwise, the
voltage low setting takes effect when the next trigger is initiated. The pulse_trig command is used
to trigger continuous or burst output.
The pulse_vlow, pulse_vhigh, and pulse_dc_output commands set the voltage value
output by the pulse channel when it is turned on (using pulse_output). If the output is already
enabled, these commands change the voltage level immediately, before the pulsing is started with a
pulse_trig command.
Example
Sets the pulse voltage low value for channel 1 of the pulse card to 0.5 V.
Also see
pulse_dc_output (on page 13-140)
pulse_output (on page 13-146)
pulse_range (on page 13-149)
pulse_trig (on page 13-152)
pulse_vhigh (on page 13-157)
