Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 6:
Clarius
4200A-901-01 Rev. C / February 2017 6-305
User library descriptions
Keithley Instruments provides several user libraries of user modules. The following topics provide an
overview of each of the user libraries.
The KULT user libraries and user modules that are provided with Clarius
+
are available in the
directory:
C:\s4200\kiuser\usrlib\
AVMControl user library
The AVMControl user library contains a user module that limits the SMU maximum voltage. The
next table lists and briefly describes the user module.
AVMControl user module
User module Description
SetAVMLevel
Sets the 4200-SMU or 4210-SMU absolute voltage monitor (AVM) maximum
voltage. The AVM is an analog circuit that limits the SMU voltage output
regardless of what the SMU is sourcing and measuring. Depending on the
voltage that the AVM is set to, the SMU clamps the output voltage to one of
the built-in voltage limits. Refer to the Help pane for the voltage limits.
BeepLib user library
The BeepLib user library contains several user modules that control the 4200A-SCS beeper. The
next table lists and briefly describes the user modules.
The beeper user modules are affected by the Windows operating system audio settings. For
example, if sound is muted, the beeper will not sound.
BeepLib user modules
User module Description
beep
Specifies the frequency and duration of the beeper.
BeepCharge
Sounds a battle cry through the speaker.
BeepDown
Sounds a series of beeps in descending tones through the speaker.
BeepInfiniteLoop
This function sounds a series of beeps through the system speaker. The
beeps continue until they are terminated.
BeepUp
Sounds a series of beeps in ascending tones through the speaker.
