9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer
9-8 4200A-901-01 Rev. C / February 2017
Logging test results
The command and message display area also displays the numerical test results for both the 4200A
and 4145 Emulation commands sets (refer to Command Set (on page 7-19
)).
You can turn off the graph display to better display a long sequence of test results. Select Hide
Graph in the upper right to hide the graph.
The test results will be 0.0000 if the interlock is disconnected.
If the sent commands include the graphics commands, the graph display area graphs the test data.
Refer to Graphing the test results (on page 9-9
) section.
Understanding the log file
If the Log Console Messages check box is selected (lower left of the user interface), KXCI logs all
GPIB commands to a file named KXCILogfile.txt. You can open the text file after KXCI is closed.
Note that whenever you open KXCI, the log file clears.
The log file is in the directory:
C:\s4200\sys\KXCI\
You can use any text editor to open the file.
Note that SMUs may return a line such as:
DATA:NAI 22.329E-09
The three characters after DATA: represent:
• The operating condition: N for normal or C if the SMU is in compliance.
• The instrument number, converted to a letter: A for SMU1, B for SMU2 and so on to letter I.
• The measurement function: V for voltage or I for current.
