Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Appendix B: Using a Model 590 C-
V Analyzer
4200A-901-01 Rev. C / February 2017 B-11
KI590ulib user library
The user modules in the KI590ulib user library are used to control the 590 C-V Analyzer. These
user modules are summarized in the table below. Also listed in the table are names of the user test
modules (UTMs) and actions in Clarius that use the user modules.
KI590ulib user modules
User module UTM or action name Description
CableCompensate590 (on page B-
12)
cable-compensate in
the
ivcvswitch
project
Performs cable compensation using known
capacitance source values.
Cmeas590 (on page B-14)
590-cmeas
Makes a single capacitance measurement.
CtSweep590 (on page B-17)
590-ctsweep
Makes a capacitance versus time
measurement.
CvPulseSweep590 (on page B-21)
590-cvpulsesweep
Makes capacitance versus voltage
measurements using a pulse sweep.
CvSweep590 (on page B-27)
590-cvsweep
Makes capacitance versus voltage
measurements using a staircase sweep.
DisplayCableCompCaps590 (on page
B-31)
display-cap-file in
the ivcvswitch project
Places capacitance source values in a
spreadsheet.
LoadCableCorrectionConstants (on
page B-33)
n/a
Reads the cable compensation parameters for
the range and frequency specified from the
cable compensation file and sends these
parameters to the 590.
SaveCableCompCaps590 (on page
B-34)
save-cap-file in the
ivcvswitch
project
Saves entered capacitance source values in a
file.
