7: Keithley Configuration Utility (KCon) Model 4200A-SCS Parameter Analyzer

Reference Manual

7-4 4200A-901-01 Rev. C / February 2017

Add an external instrument

To add a supported external instrument to the system configuration, select Add External Instrument.

The supported instrument categories are:

• Switch Matrix

• Capacitance Meter

• Pulse Generator

• Probe Station

• Test Fixture

• General Purpose Test Instrument

Supported external instrumentation and equipment are controlled by Clarius user test modules

(UTMs). Keithley Instruments provides libraries of user modules for each supported external

instrument (refer to Supported external equipment (on page 7-6

)). You can modify these libraries or

create your own using the Keithley User Library Tool (KULT).

For additional information regarding external instrumentation and user modules, refer to Keithley User

Library Tool (KULT) (on page 8-1).
