Model 4200A

-SCS Parameter Analyzer Reference Manual Appendix I:

Using a manual or fake prober

4200A-901-01 Rev. C / February 2017 I-3

Modifying the prober configuration file

You can modify these files using the 4200A-SCS.

The default prober configuration file for a manual prober (MANL) is listed below. The only relevant

line for this prober type is PROBER_1_PROBTYPE=MANL.

# prbcnfg.dat - EXAMPLE Prober Configuration File MANL Prober

# The following tag, "PRBCNFG", is used by the engine in order to determine

# the MAX number of SLOTS and CASSETTES for a given prober at runtime.

# for OPTIONS "" == NULL, max 32 chars in string

# Example

# 01234567890

#PROBER_1_OPTIONS=1,1,1,1,1,1

# OcrPresent

# AutoAlnPresent

# ProfilerPresent

# HotchuckPresent

# HandlerPresent

# Probe2PadPresent

# Configuration for MANuaL probers (S900NT):

# MANL

PROBER_1_PROBTYPE=MANL

PROBER_1_OPTIONS=0,0,0,0,1,0

PROBER_1_IO_MODE=GPIB

PROBER_1_GPIB_UNIT=0

PROBER_1_GPIB_SLOT=1

PROBER_1_GPIB_ADDRESS=5

PROBER_1_GPIB_WRITEMODE=0

PROBER_1_GPIB_READMODE=2

PROBER_1_GPIB_TERMINATOR=10

PROBER_1_TIMEOUT=300
