Section

6: Clarius Model 4200A-SCS Parameter Analyzer

Reference Manual

6-244 4200A-901-01 Rev. C / February 2017

Figure 380: A2, A3, and A4 curve areas

Figure 381: A5 curve area

You can use this function to do calculations in real time (while a test is executing).

Example

QBD = INTEG(TIME, GATEI)

Also see

None

LASTPOS Formulator function

Returns the row number (index) of the last value in a column (vector).

Usage

LASTPOS(Value)

Value

The name of any column (vector) listed under Columns

Example

NUMSWEEPPTS = LASTPOS(COLLECTORI)

Also see

FIRSTPOS (on page 6-241)
