Model 4200A

-SCS Parameter Analyzer Reference Manual Section 13:

LPT library function reference

4200A-901-01 Rev. C / February 2017 13-47

trigcomp

This command causes a trigger when an instrument goes in or out of compliance.

Usage

int trigcomp(int instr_id, int mode);

instr_id

The instrument identification code the trigger is set to

mode

Specifies whether to trigger when an instrument is in or out of compliance:

• 1: Trigger when in compliance

•

: Trigger when out of compliance

Details

This command monitors the given instrument for compliance. A trigger can be set when the

instrument is either in compliance or out of compliance, based on the specified mode.

Also see

None

trigXg, trigXl

This command monitors for a predetermined level of voltage, current, or time.

Usage

int trigig(int instr_id, double value);

int trigil(int instr_id, double value);

int trigtg(int instr_id, double value);

int trigtl(int instr_id, double value);

int trigvg(int instr_id, double value);

int trigvl(int instr_id, double value);

instr_id

The instrument identification code of the monitoring instrument

value

The voltage, current, or time specified as the trigger point; this trigger point value is

reached when either of the following occurs:

• The measured value is equal to or greater than the value argument of the

trigXg command

• The measured value is less than the value argument of the trigXl

command
