-SCS Parameter Analyzer Reference Manual Section 6:
4200A-901-01 Rev. C / February 2017 6-321
wlrlib user library
The user modules in the wlrlib user library run linear regression and charge-to-breakdown (Q
BD
)
ramp tests for wafer-level reliability (WLR) testing. These user modules are summarized in the table
below.
wlrlib user modules
User module Description
Performs simple linear regression.
Performs a charge-to-breakdown test using the
QBD V-ramp test.
Performs a charge-to-breakdown test using the
For more information, refer to Wafer-Level Reliability Testing (on page L-1).
Winulib user library
The Winulib user library provdes user interface routines for operator inputs and prompts, such as
abort, retry, and ignore decision prompts.
Winulib user modules
User Module Clarius Action Name Description
(on page 6-322)
This user module creates a dialog box with
Abort, Retry, and Ignore decision prompts.
page 6-323)
This user module creates a dialog box that
can prompt for up to four input parameters.
page 6-325)
This user module creates a dialog box that
provides OK or Cancel decisions.
326)
This user module creates a dialog box that
pauses the test sequence to make an
announcement (for example, "Test
finished") or prompt for an action (for
example, connection change).
page 6-328)
This user module creates a dialog box that
presents Retry or Cancel decisions.
page 6-329)
This user module creates a dialog box that
contains up to four lines of text and Yes,
331)
This user module creates a dialog box that
contains up to four lines of text and Yes
