Model 4200A

-SCS Parameter Analyzer Reference Manual Appendix J: Using a Cascade Summit-

12000 Prober

4200A-901-01 Rev. C / February 2017 J-27

Commands and error symbols

The following table contains error and status symbols listed by command.

Available commands and responses

PrChuck PrInit PrMovNxt PrSSMovNxt

PR_OK

BAD_CHUCK

INVAL_MODE

UNINTEL_RESP

INVAL_PARAM

BAD_MODE

UNEXPE_ERROR

PR_WAFERCOMPLETE

Information and error code return values and descriptions

Value Constant Explanation

PR_OK

Command executed properly

PR_MOVECOMPLETE

Prober moved to next die (confirmed)

PR_WAFERCOMPLETE

Next wafer loaded (confirmed)

-1006

INVAL_MODE

Invalid mode

-1008

SET_MODE_FAIL

Failure setting mode

-1011

BAD_MODE

Operation invalid in mode

-1013

UNINTEL_RESP

Unintelligible response

-1014

MOVE_FAIL

Movement failure

-1015

UNEXPE_ERROR

Unexpected error number

-1017

BAD_CHUCK

Bad chuck position

-1027

INVAL_PARAM

Invalid parameter
