8: Keithley User Library Tool (KULT) Model 4200A-SCS Parameter Analyzer
8-8 4200A-901-01 Rev. C / February 2017
The edit menu commands are:
• New: Deletes the present description from the description tab area, allowing you to enter a new
description.
• Include: Imports any file that you specify, typically a text file, into the document tab area. Refer to
Include (on page 8-11
).
• Cut: Removes highlighted text from the Description tab and copies it to the clipboard. The text on
the clipboard can be restored to new locations, in or out of KULT, using the paste function.
• Copy: Copies highlighted text from the description tab area to the clipboard. The text on the
clipboard can be placed at new locations, in or out of KULT, using the paste function.
• Paste: Places text from the clipboard at a selected location in the Description tab area.
• Select All: Selects everything in the Description tab area.
Build tab area
The Build tab area displays any error or warning messages that are generated during a code
compilation or build operation of the user library. When you click a compilation error message that is
displayed in the Build tab area, KULT highlights either the line of code where the error occurred or the
next line, depending on how the compiler caught the error. KULT also highlights the error message.
This helps you correct errors.
If no errors are found, the Build tab area displays one of the following:
• After a compilation: No Errors/Warnings Reported, Compilation was Successful.
• After a build: No Errors/Warnings Reported, Library Build was Successful.
Understanding the status bar
The status bar at the bottom of the KULT dialog box displays a description of the area where the
cursor is located. For example, if the cursor is in the Parameters tab area, the status bar describes
that area, as shown in the following figure.
Figure 424: Example of description in status bar
