SaveCableCompCaps82 user module
The user modules saves the nominal values of the capacitors used with the 590 cable compensation
procedure to a file.
Usage
status = SaveCableCompCaps82(char *CabCompFile, double Lo2p100k, double Lo2p1M,
double Hi2p100k, double Hi2p1M, double Lo20p100k, double Lo20p1M, double
Hi20p100k, double Hi20p1M, double Lo200p100k, double Lo200p1M, double
Hi200p100k, double 200p1M, double Lo2n100k, double Lo2n1M, double Hi2n100k,
double Lo2n1M);
CabCompFile
The complete name and path for the cable compensation file; see Details
Lo2p100k
The nominal value of the low range capacitor used to perform cable compensation
for the 2 pF range and 100 kHz frequency: 0 F to 0.95E-12 F
Lo2p1M
The nominal value of the low range capacitor used to perform cable compensation
for the 2 pF range and 1 MHz frequency: 0 F to 0.95E-12 F
Hi2p100k
The nominal value of the high range capacitor used to perform cable compensation
for the 2 pF range and 100 kHz frequency: 1E-12 F to 2E-12 F
Hi2p1M
The nominal value of the high range capacitor used to perform cable compensation
for the 2 pF range and 1 MHz frequency: 1E-12 F to 2E-12 F
Lo20p100k
The nominal value of the low range capacitor used to perform cable compensation
for the 20 pF range and 100 kHz frequency: 0 F to 9.5E-12 F
Lo20p1M
The nominal value of the low range capacitor used to perform cable compensation
for the 20 pF range and 1 MHz frequency: 0 F to 9.5E-12 F
Hi20p100k
The nominal value of the high range capacitor used to perform cable compensation
for the 20 pF range and 100 kHz frequency: 10E-12 F to 20E-12 F
Hi20p1M
The nominal value of the high range capacitor used to perform cable compensation
for the 20 pF range and 1 MHz frequency: 10E-12 F to 20E-12 F
Lo200p100k
The nominal value of the low range capacitor used to perform cable compensation
for the 200 pF range and 100 kHz frequency: 0 F to 95E-12 F
Lo200p1M
The nominal value of the low range capacitor used to perform cable compensation
for the 200 pF range and 1 MHz frequency: 0 F to 95E-12 F
Hi200p100k
The nominal value of the high range capacitor used to perform cable compensation
for the 200 pF range and 100 kHz frequency: 100E-12 F to 200E-12 F
Hi200p1M
The nominal value of the high range capacitor used to perform cable compensation
for the 200 pF range and 1 MHz frequency: 100E-12 F to 200E-12 F
Lo2n100k
The nominal value of the low range capacitor used to perform cable compensation
for the 2 nF range and 100 kHz frequency: 0 F to 995E-12 F
Lo2n1M
The nominal value of the low range capacitor used to perform cable compensation
for the 2 nF range and 1 MHz frequency: 0 F to 995E-12 F
Hi2n100k
The nominal value of the high range capacitor used to perform cable compensation
for the 2 nF range and 100 kHz frequency: 1000E-12 F to 2000E-12 F
Hi2n1M
The nominal value of the high range capacitor used to perform cable compensation
for the 2 nF range and 1 MHz frequency: 1000E-12 F to 2000E-12 F
