Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 6:
Clarius
4200A-901-01 Rev. C / February 2017 6-311
HP8110ulib user library
Use the user modules in the HP8110ulib user library to control a Keysight Model 8110A Pulse
Generator. These user modules are summarized in the following table. The table also lists the user
test modules (UTM) created by Keithley Instruments that use the user modules.
HP8110ulib user modules
User Module UTM Name Description
PguInit8110 (on
page E-5)
pgu1-init
Initializes the pulse generator to the default setup.
PguSetup8110 (on
page E-6)
pgu1-setup
Sets the output pulse parameters.
PguTrigger8110 (on
page E-8)
pgu-trigger
Specifies pulse count and trigger start of output.
ki340xulib user library
Used with the Keithley Instruments Series 3400 pulse/pattern generators.
ki340xulib user modules
User module Description
PguInit340x
Initializes the 3401 or 3402 pulse generator to a specific state.
PguSetup340x
Defines the pulse timing and voltage settings. Once defined, the pulse
can be triggered using the
PguTrigger340x
command.
PguTrigger340x
Triggers the pulse (or pulses) defined by the PguSetup340x function.
KI42xxulib user library
The KI42xxulib user library provides an example subroutine for doing a MOSFET ON resistance
(R
ON
) test routine using the 4200A-SCS LPT library interface.
KI42xxulib user module
User module UTM name Description
Rdson42XX
rdson
Measures the drain to source resistance of a saturated MOSFET.
