Model 4200A

-SCS Parameter Analyzer Reference Manual Section 6:

Clarius

4200A-901-01 Rev. C / February 2017 6-235

ATAN Formulator function

Returns the arc tangent of each value in a designated column (vector) under Columns or any operand.

Usage

ATAN(Value)

Value

The name of any column (vector) in the Data Series list or any operand

Details

Returns the value in radians.

Example

F1 = ATAN(DRAINI)

Also see

None

COS Formulator function

Returns the cosine of each value operand.

Usage

COS(Value)

Value

The name of any column (vector) in the Data Series list or any operand

Details

Returns the value in radians.

Example

F1 = COS(DRAINI)

Also see

None
