Section

6: Clarius Model 4200A-SCS Parameter Analyzer

Reference Manual

6-282 4200A-901-01 Rev. C / February 2017

LOG10 Calc worksheet function

This command returns the base-10 logarithm of a value.

Usage

LOG10(Value)

Value

Any positive real number

Example

=LOG10(260)

=LOG10(100)

Returns 2.4149E+0.

Returns

2.0000E+0

.

Also see

EXP (on page 6-279)

LN (on page 6-281)

LOG (on page 6-281)
