-SCS Parameter Analyzer Reference Manual Section 6:
4200A-901-01 Rev. C / February 2017 6-309
hivcvulib user library
The hivcvulib user library contains user modules for controlling high-voltage C-V measurements.
You can use these modules with either one or two 4205-RBT configurations. The next table lists and
briefly describes the user modules.
hivcvulib user modules
User module Description
Provides capacitance measurements as a function of time at a user-
specified DC bias. You can measure capacitance up to 200 V DC bias
with one 4205-RBT and one SMU. Additionally, you can measure
capacitance up to 400 V DC bias with two 4205-RBTs and two SMUs.
Uses one 4205-RBT to sweep a DC voltage across the DUT using the
4200-SMU or 4210-SMU and measure the capacitance using the
4210-CVU. If two 4205-RBTs are used with the SweepV module, one
SMU sweeps the DC voltage and the other SMU applies an offset DC
Hotchuck_Temptronics3010B user library
This user library controls the temperature of Temptronics 3010B hotchucks. The user module in this
library sets the target temperature and waits until the target is reached before exiting.
Hotchuck_Temptronics3010B user module
User module Description
This routine controls the Temptronics thermal controller 3010B and other
compatible models.
Hotchuck_Triotek user library
The user module in the Hotchuck_Triotek user library is used to control the temperature of the
Trio-Tech hot chuck.
Hotchuck_Triotek user module
User module Description
Sets the temperature of the Trio-Tech hot chuck.
HP4284ulib user library
You use the user modules in the HP4284ulib user library to control the Keysight 4284A or 4980A
LCR Meter. These user modules are summarized in the following table.
HP4284ulib user library
User module Description
Makes a single capacitance measurement.
CvSweep4284 (on page
C-9)
Makes capacitance versus voltage measurements using a staircase sweep.
