Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 6:
Clarius
4200A-901-01 Rev. C / February 2017 6-313
ki82ulib user library
The user modules in the ki82ulib user library control the Model 82 C-V System. They perform
simultaneous C-V, C-t, and Q/t measurements and cable compensation. The next table lists the user
modules. It also provides the name of tests and actions in Clarius that are based on these user
modules.
ki82ulib user modules
User module
Test and action
names Description
Abortmodule82 (on page D-
29)
n/a
Puts the three System 82 instruments into a known
state when a test is aborted. This function is used by
other library modules in the
atexit()
function.
CableCompensate82 (on
page D-30)
cable-compensate
cablecomp
Performs cable compensation using known
capacitance source values.
CTsweep82 (on page D-33)
ctsweep
Performs C-t measurements.
DisplayCableCompCaps82
(on page D-36)
display-cap-file
Places capacitance source values in a spreadsheet.
LoadCableCorrectionCon
stants82
n/a
Read the cable compensation parameters and sends
them to the 590. This module is for internal use by the
SIMCVsweep82 and CTsweep82 modules. It is not
normally used as a stand-alone module.
QTsweep82 (on page D-38)
qtsweep
Performs quasistatic measurement sweep.
SaveCableCompCaps82 (on
page D-41)
save-cap-file
savecablecompfile
Saves entered capacitance source values in a file.
SIMCVsweep82 (on page D-
44)
system82-cvsweep
cvsweep
Performs simultaneous C-V sweep.
LS336ulib user library
The LS366ulib provides user modules that control the Lake Shore Cryotronics 336 Temperature
Controller.
LS336ulib user modules
User module Description
heaterOff
Turns off heater 1 and heater 2 and disables setpoint ramping on both outputs.
setDelay_Dialog
Either displays a window that contains the message you specified and an OK
button, or performs the delay set by
WaitTime
.
setSweepParams
Generates the list of temperatures used by setTemp when the setTemp
parameter FlagMode is set to 1. When active, it calculates the temperature
profile to be measured from the start temperature, stop temperature, and step
points input. It outputs the temperature list to the file.
setTemp
Controls key aspects of the temperature controller, including setpoint, heater
parameters, and ramp rates, to allow variable temperature electrical
measurements. This routine is designed to function inside a subsite cycle test
with the
heaterOff
and
setSweepParam
routines.
