13: LPT library function reference Model 4200A-SCS Parameter Analyzer
Reference Manual
13-6 4200A-901-01 Rev. C / February 2017
Command Description
pulse_train (on page 13-
123)
PGU, PMU. Configures the pulse card to output a pulse train using fixed voltage
values.
rpm_config (on page 13-
124)
PMU with 4225-RPM. Sends switching commands to the 4225-RPM.
seg_arb_sequence (on
page 13-125)
PGU, PMU. Defines the parameters for a Segment Arb waveform pulse-measure
sequence.
seg_arb_waveform (on
page 13-128)
PGU, PMU. Creates a voltage segment waveform.
setmode (LLEC) (on
page 13-129)
PMU. Sets the number of iterations for load-line effect compensation (LLEC) for the
PMU.
Pulse source only (PG2) commands
In the LPT commands, the pulse-only module (4220-PGU) is referred to as VPU1, VPU2, and so on.
The pulse-measure module (4225-PMU) is referred to as PMU1, PMU2, and so on. The 4210-CVU is
referred to as CVU1, CVU2, and so on.
Note that the 4225-PMU and 4220-PGU support the PG2 commands.
Command Description
arb_array (on page 13-
131)
Used to define a full-arb waveform and name the file.
arb_file (on page 13-132) Loads a waveform from an existing full-arb waveform file.
devclr (on page 13-67)
Sets all sources to a zero state.
devint (on page 13-13)
Resets all active instruments in the system to their default states.
getstatus (on page 13-
70)
Returns the operating state of a specified instrument.
pg2_init (on page 13-
137)
Resets the pulse card to the specified pulse mode (standard, full arb, or Segment
Arb) and its default conditions.
pulse_burst_count (on
page 13-138)
For the burst mode, this command sets the number of pulses to output during a
burst sequence.
pulse_current_limit (on
page 13-139)
Sets the current limit of the pulse card.
pulse_dc_output (on
page 13-140)
Selects the DC output mode and sets the voltage level.
pulse_delay (on page 13-
141)
Sets the delay time from the trigger to when the pulse output starts.
pulse_fall (on page 13-
142)
Sets the fall transition time for the pulse output.
pulse_halt (on page 13-
143)
Stops all pulse output from the pulse card.
pulse_init (on page 13-
144)
Resets the pulse card to the default settings for the pulse mode that is presently
selected.
pulse_load (on page 13-
145)
Sets the output impedance for the load (DUT).
pulse_output (on page
13-146)
Sets the pulse output of a pulse card channel on or off.
pulse_output_mode (on
page 13-147)
Sets the pulse output mode of a pulse card channel.
pulse_period (on page
13-148)
Sets the period for pulse output.
