G: Using a Cascade Microtech PA200 Prober Model 4200A-SCS Parameter Analyzer

Reference Manual

G-20 4200A-901-01 Rev. C / February 2017

8. Select File > Project > Save to save the WaferMap configuration.

Figure 660: PA200 WaferMap: Save

Clarius probesubsites project example

The following is a step-by-step procedure to configure the PA-200 so the probesubsites Clarius

project executes successfully.

On the ProberBench NT computer:

1. Select the ProberBench NT icon (shortcut) on the desktop.

Figure 661: ProberBench NT icon

Default Chapter4
