J: Using a Cascade Summit-12000 Prober Model 4200A-SCS Parameter Analyzer

Reference Manual

J-8 4200A-901-01 Rev. C / February 2017

# prbcnfg_CC12K.dat - DEFAULT Prober Configuration File

# The following tag, "PRBCNFG", is used by the engine in order to determine

# the MAX number of SLOTS and CASSETTES for a given prober at runtime.

# for OPTIONS "" == NULL, max 32 chars in string

# Example

# 01234567890

#PROBER_1_OPTIONS=1,1,1,1,1,1

#OcrPresent

#AutoAlnPresent

#ProfilerPresent

#HotchuckPresent

#HandlerPresent

#Probe2PadPresent

# Configuration for direct GPIB probers:

# CC12K

PROBER_1_PROBTYPE=CC12K

PROBER_1_OPTIONS=0,0,0,0,1,0

PROBER_1_IO_MODE=GPIB

PROBER_1_GPIB_UNIT=0

PROBER_1_GPIB_SLOT=1

PROBER_1_GPIB_ADDRESS=28

PROBER_1_GPIB_WRITEMODE=0

PROBER_1_GPIB_READMODE=2

PROBER_1_GPIB_TERMINATOR=13

PROBER_1_TIMEOUT=300

PROBER_1_SHORT_TIMEOUT=5

PROBER_1_MAX_SLOT=25

PROBER_1_MAX_CASSETTE=1

Set up wafer geometry

On the probe station computer:

1. If the Nucleus toolbar is not already open, double-click the Nucleus icon on the Windows

desktop.

Figure 748: Nucleus icon
