Appendix

H: Using a Micromanipulator 8860 Prober Model 4200A-SCS Parameter Analyzer

Reference Manual

H-28 4200A-901-01 Rev. C / February 2017

PR_OK

X X X X

BAD_CHUCK

X X

UNINTEL_RESP

X X X X

BAD_MODE

X X

UNEXPE_ERROR

PR_WAFERCOMPLETE

X X

SET_MODE_FAIL

MOVE_FAIL

X X

Information and error code return values and descriptions

Value Constant Explanation

1 PR_OK

Command executed properly

2 PR_MOVECOMPLETE

Prober moved to next die (confirmed)

4 PR_WAFERCOMPLETE

Next wafer loaded (confirmed)

-1006 INVAL_MODE

Invalid mode

-1008 SET_MODE_FAIL

Failure setting mode

-1011 BAD_MODE

Operation invalid in mode

-1013 UNINTEL_RESP

Unintelligible response

-1014 MOVE_FAIL

Movement failure

-1015 UNEXPE_ERROR

Unexpected error number

-1017 BAD_CHUCK

Bad chuck position

-1027 INVAL_PARAM

Invalid parameter

Commands and error symbols

The following list contains error and status symbols listed by command.

Available commands and responses

PrChuck PrInit PrMovNxt PrSSMovNxt
