Programming example #5
Similar to Programming example #4 (on page 13-197), but the Delay is set to 0 s, and an array of
delay values is used for the sweep (0.5 s, 0.25 s, 0.5 s, and 0.25 s).
double result1[4], result2[4], forceArray[4], delayArray[4];
setfreq(CVU1, 100e3); /* Set AC drive frequency to 100 kHz. */
setlevel(CVU1, 15e-3); /* Set AC drive voltage to 15 mV RMS. */
setauto(CVU1); /* Select auto measure range. */
smeasz(CVU1, KI_CVU_TYPE_CPGP, KI_CVU_SPEED_NORMAL, result1, result2);
/* Configure CpGp measurements. */
adelay(4, delayArray); /* Call a delay array for asweepv. */
asweepv(CVU1, 4, 0, forceArray); /* Configure and perform sweep. */
devint(); /* Reset CVU. */
LPT commands for switching
These LPT commands are used with the Series 700 Switching System, the 4200A-CVIV Multi-Switch,
and the 4225-RPM.
addcon
This command adds connections without clearing existing connections.
Usage
int addcon(int exist_connect, int connect1, [connectn, [...]] 0);
exist_connect
An instrument terminal ID; this instrument or terminal may have been, but is not
required to have been, previously connected with the addcon, conpin, or conpth
command
connect1
A pin number or an instrument terminal ID
connectn
A pin number or an instrument terminal ID
Details
addcon can be used to make additional connections on a matrix. addcon will connect every item in
the argument list together, and there is no real distinction between exist_connect and the rest of
the connection list. addcon behaves like the conpin command, except previous connections are
never cleared.
The value -1 will be ignored by addcon and is considered a valid entry in the connection list.
However, exist_connect may not be -1.
With the row-column connection scheme, only one instrument terminal may be connected to a pin.
Before making the new connections, the addcon command clears all active sources by calling the
devclr command.
Also see
clrcon (on page 13-199)
conpin (on page 13-199)
conpth (on page 13-200)
delcon (on page 13-204)
