odel 4200A-SCS Parameter Analyzer Reference Manual Section 6:
4200A-901-01 Rev. C / February 2017 6-17
Create a new project from My Projects
You can create a new project from the My Projects dialog box. This is the same as creating a new
empty project from the Project Library "New Project" option.
To create a new project:
1. Open My Projects.
2. Select Create New. A confirmation message is displayed.
3. Select Yes. The new project replaces the existing project and closes the My Projects dialog box.
4. In the project tree, select Rename to assign a new name to the project.
5. Press Enter to accept the new name.
Export a project
You can export a project. An exported project can be imported into another 4200A-SCS.
The export includes all Run History data for each test in the project.
To export a project:
1. In Clarius, select My Projects.
2. Select the project to be exported.
3. Select Export. The Export From My Projects dialog box opens.
4. Select the location for the exported file. You can right-click to select options to create a new
folder, rename an existing folder, or delete a folder.
5. Select Export.
Import a project
You can import a project from another 4200A-SCS.
You can import either an exported project or a project directory.
Exported projects have the extension kzp. Refer to Export a project (on page 6-17
) for instructions.
If you are importing a project directory, you import the kpr file from that directory. The import includes
all files from the project directory, assuming that the project directory is valid.
Make sure that the files that you are importing are not set to read-only or run-only.
