G: Using a Cascade Microtech PA200 Prober Model 4200A-SCS Parameter Analyzer
G-26 4200A-901-01 Rev. C / February 2017
5. Select the Karl Suss PA200 Prober as the model.
6. Ensure that the Number of Pins / Positioners is correct. The number of pins defined here
determines the pins that are available to assign to a switch matrix card column.
7. Select Save.
8. Exit KCon.
Running projects
On the ProberBench NT computer:
1. After the wafer is set up and alignment is complete, select the File > Project > Save.
2. Select File > Map > Save.
3. Select File > Table > Save. The wafer is ready to probe.
4. Place the prober in Run mode.
5. Ensure that the "E" in the WaferMap toolbar is selected.
Figure 672: WaferMap toolbar
Clarius
Use Clarius to load and run the probesites or probesubsites project using the new KCon
configuration file, which allows you to execute the project for this prober.
On the 4200A-SCS:
1. Open Clarius.
2. Choose Select.
3. Select Projects.
4. Search for probesubsites.
5. Drag the probesubsites project to the project tree.
