13: LPT library function reference Model 4200A-SCS Parameter Analyzer
13-176 4200A-901-01 Rev. C / February 2017
getstatus
This command returns various parameters pertaining to the state of the 4210-CVU.
Usage
int getstatus(int instr_id, long parameter, double *value);
The instrument identification code of the 4210-CVU:
Parameter to be queried; the macros for the KI_CVU parameters are defined in
Returned value for the queried parameter
Details
Parameter: Returns:
Load compensation (ON or OFF)
Open compensation (ON or OFF)
Short compensation (ON or OFF)
Current length setting for which the CVU card is correcting (0, 1.5, or 3)
AC current range (0 for auto range, or 1.5 µA, 50 µA, or 1.5 mA for fixed
range)
AC current range (1.5 µA, 50 µA or 1.5 mA); returns range used for last
measurement, even if on auto range
AC voltage level (10 mV to 100 mV
RMS
)
A/D aperture time (0.006 to 10.002 PLCs)
Integration (NPLC= 1/aperture time)
DC bias voltage level (−30 V to 30 V)
Drive frequency (1 kHz to 10 MHz)
Impedance measure model (0 through 5; see "Measurement model
parameter values" table below)
Measurement speed (fast, normal, quiet or custom)
Measurement status (for last reading); the measurement status codes are
listed and explained in Status codes (on page 6-192)
Measurement timestamp (for last reading)
Measurement model parameter values
Impedance (Z) and phase (θ in degrees)
RjX Resistance and reactance
or
Parallel capacitance and conductance
Series capacitance and resistance
CpD Parallel capacitance and dissipation factor
or
Series capacitance and dissipation factor
