rpm_config
This command sends switching commands to the 4225-RPM.
Usage
int rpm_config(int instr_id, long chan, long modifier, long value);
instr_id
The instrument identification code: PMU1, PMU2, and so on
chan
Channel number of the pulse generator:
1
or
2
modifier
Parameter to modify:
KI_RPM_PATHWAY
value
Value to set modifier:
• KI_RPM_PULSE or 0: Selects pulsing (4225-RPM)
• KI_RPM_CV_2W or 1: Selects 2-wire CVU (4210-CVU)
• KI_RPM_CV_4W or 2: Selects 4-wire CVU (4210-CVU)
•
KI_RPM_SMU or 3: Selects SMU (4200-SMU)
Pulsers
4225-PMU with the 4225-RPM
Pulse mode
Standard (two-level pulsing), Segment Arb, and full arb
Details
The 4225-RPM includes input connections for the 4210-CVU and 4200-SMU. Use this command to
control switching inside the RPM to connect the PMU, CVU, or SMU to the output.
When using the PMU with the RPM, rpm_config must be called to connect the pulse source to the
RPM output. Note that if there is no RPM connected to the PMU channel, the rpm_config command
will not cause an error. The RPM connection is cleared by the clrcon command.
Example
rpm_config(PMU1, 1, KI_RPM_PATHWAY, KI_RPM_PULSE);
This example sets channel 1 of the RPM for pulsing.
Also see
clrcon (on page 13-199)
