Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 13:
LPT library function reference
4200A-901-01 Rev. C / February 2017 13-191
smeaszRT
This command makes and returns impedance measurements for a voltage or frequency sweep in real time.
Usage
int smeaszRT(int instr_id, long model, long speed, double *result1, char *colname1,
double *result2, char *colname2);
instr_id
The instrument identification code of the 4210-CVU: CVU1
model
Measure model (see "Measurement model parameter values" table in Details)
speed
Speed settings:
• KI_CVU_SPEED_FAST: Fast measurements (higher noise)
• KI_CVU_SPEED_NORMAL: Selects a balance between speed and low noise
• KI_CVU_SPEED_QUIET: Low-noise measurements
• KI_CVU_SPEED_CUSTOM: Selects custom settings; the delay factor, filter
factor, and aperture are set using the
setmode
command
result1
Array of the first result of the selected measure model
colname1
Column name to pass into Clarius for result1 array (character string)
result2
Array of the second result of the selected measure model
colname2
Column name to pass into Clarius for result2 array (character string)
Details
This command is similar to the smeasz command; both commands return the measured impedance
readings for a sweep returned in arrays. However, the readings from smeaszRT are posted to the
Clarius Analyze sheet and graph in real time. Two measurement results appear in the sheet and
graph after each step of the sweep is executed.
Note that the values are only available in real-time if Clarius is running. Otherwise, they are stored in
an array.
The colname1 and colname2 parameters specify names for data sheet columns in Clarius.
Measurement model parameter values
Measurement model
Parameter value
ZTH
Impedance (Z) and phase (θ in degrees)
KI_CVU_TYPE_ZTH
or
0
RjX
Resistance and reactance
KI_CVU_TYPE_RJX
or
1
CpGp
Parallel capacitance and conductance
KI_CVU_TYPE_CPGP
or
2
CsRs Series capacitance and resistance
KI_CVU_TYPE_CSRS
or
3
CpD
Parallel capacitance and dissipation factor
KI_CVU_TYPE_CPD
or
4
CsD
Series capacitance and dissipation factor
KI_CVU_TYPE_CSD
or
5
Example
smeaszRT(CVU1, 2, KI_NORMAL, result1, "result1", result2, "result2");
This command posts the results into the Clarius data sheet under columns named result1_arr and
result2_arr.
Also see
smeasz (on page 13-189)
