Keithley 4200A-SCS Reference Manual

Appendix
E: Using a Keysight 8110A/8111A Pulse Generator Model 4200A-SCS Parameter Analyzer
Reference Manual
E-4 4200A-901-01 Rev. C / February 2017
Using KCon to add a Keysight pulse generator to the system
In order for the 4200A-SCS to control an external instrument, that instrument must be added to the
system configuration. The pulse generator is added to the test system using the Keithley
Configuration Utility (KCon).
Refer to Using KCon to add equipment to the 4200A-SCS (on page 7-7
) for instruction.
For additional detail on KCon, refer to Keithley Configuration Utility (on page 7-1).
HP8110ulib user library
Use the user modules in the HP8110ulib user library to control a Keysight Model 8110A Pulse
Generator. These user modules are summarized in the following table. The table also lists the user
test modules (UTM) created by Keithley Instruments that use the user modules.
HP8110ulib user modules
User Module UTM Name Description
PguInit8110 (on
page E-5)
pgu1-init
Initializes the pulse generator to the default setup.
PguSetup8110 (on
page E-6)
pgu1-setup
Sets the output pulse parameters.
PguTrigger8110 (on
page E-8)
pgu-trigger
Specifies pulse count and trigger start of output.
