Figure 673: probesubsites project tree

6. Click Run.

Commands and error symbols

The following table contains error and status symbols listed by command.

Available commands and responses

PrChuck PrInit PrMovNxt PrSSMovNxt

PR_OK

BAD_CHUCK

INVAL_MODE

UNINTEL_RESP

INVAL_PARAM

BAD_MODE

UNEXPE_ERROR

PR_WAFERCOMPLETE
