Keithley 4200A-SCS Reference Manual

Section
5: Pulse measure and pulse generator units Model 4200A-SCS Parameter Analyzer
Reference Manual
5-2 4200A-901-01 Rev. C / February 2017
LPT functions that pertain to the PGU and PMU are documented in LPT commands for PGUs and
PMUs (on page 13-91).
KPulse: The Keithley Pulse (KPulse (on page 10-1)) application supports the PGU.
The pulse source-measure concepts covered in this section apply to the PGU and PMU.
The simplified circuits of the 4220-PGU and 4225-PMU pulse generators are shown in the next figure.
Figure 141: Simplified circuits of the PGU and PMU
PGU and PMU connectors
The connectors for the PGU and PMU pulse cards are shown in the next figure.
Figure 142: 4220-PGU and 4225-PMU connectors
