Keithley 4200A-SCS Reference Manual

Section
9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer
Reference Manual
9-12 4200A-901-01 Rev. C / February 2017
Data output and file commands
The data output and file commands command strings are valid in any system mode page. They are:
• DO command: Obtain output data (on page 9-36)
• SR command: Set fixed source range (on page 9-39)
• SV command: Save file (on page 9-37)
• GT command: Get file (on page 9-37)
• MP command: Map channel (on page 9-38)
User mode commands
The user mode commands are listed in the following. Full descriptions are provided in User mode
commands (on page 9-39).
• DV and DI commands: SMU setup (on page 9-40)
• DS Command: VS1...VS9 setup (on page 9-41)
• TV and TI commands: Triggering (on page 9-42)
Commands common to system and user modes
Some commands are common to the system and user modes, as listed below. Descriptions of these
commands are provided in Commands common to system and user modes (on page 9-43
).
• IT command: Set integration time (on page 9-44)
• ID command: Retrieve instrument ID (on page 9-45)
• DR: Control service request for Data Ready (on page 9-45)
• BC command: Clear data buffer (on page 9-46)
• RS command: Set global measurement resolution (on page 9-46)
• RI command: Instruct a SMU to go a specified range (on page 9-46)
• RG command: Set the lowest current-measurement range (on page 9-47)
• AC command: Perform autocalibration (on page 9-47)
• EC command: Exit on compliance (on page 9-48)
• EM command: Switch between 4145 and 4200 modes (on page 9-48)
4200A command set only
The 4200A command set only command is:
• *OPT?: Get KXCI configuration of the 4200A-SCS (on page 9-49)
