Section

9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer Reference Manu

9-42 4200A-901-01 Rev. C / February 2017

TV and TI

These commands trigger a measurement.

Usage

AABB

Type of measurement:

• Voltage: TV

• Current:

Measure channel for voltage measurements:

• SMU1: 1

• SMU2: 2

• SMU3: 3

• SMU4: 4

• VM1: 5

• VM2: 6

• SMU5: 7

• SMU6: 8

• SMU7: 9

• SMU8: 10

• VM3: 11

• VM4: 12

• VM5: 13

• VM6: 14

• VM7: 15

•

VM8: 16

Measure channel for current measurements:

• SMU1: 1

• SMU2: 2

• SMU3: 3

• SMU4: 4

• SMU5: 5

• SMU6: 6

• SMU7: 7

•

SMU8: 8
