Step 3. Is the pulse level correct for each channel?
1. If the pulse level is not correct for each channel, enable load-line effect compensation (LLEC). To
compensate for the IR drop effect, the LLEC algorithm applies multiple pulses at each sweep
step; make sure that the DUT behavior is not adversely affected by the LLEC approach. See
Controlling LLEC from an ITM (on page 5-39, on page 5-40
).
2. Run the test again and compare results. If the results match the test settings, the issue was the
lack of LLEC.
The load-line effect can reduce the voltage level at the DUT terminal when current is flowing. See
Load-line effect compensation (LLEC) for the PMU (on page 5-34
).
Refer to Step 4. Is the pulse I-V curve suspect? (on page 5-50) for examples with LLEC disabled and
enabled.
Step 4. Is the pulse I-V curve suspect?
If the waveform has a good shape (Step 2. Verify the pulse shape), and the pulse level is correct
(Step 3. Is the pulse level correct for each channel?), but the pulse I-V curve is suspect, perform the
steps below.
In this procedure, you set test parameters to provide boundaries for the test envelope. When load-line
effect compensation (LLEC) is disabled, the source voltage must be bounded.
LLEC may not respond properly for a high-gain transistor (for example, a compound semiconductor-
based amplifier or power transistor).
If the pulse I-V curve is suspect:
1. Disable the load line for the gate and drain in the Key Parameters. For an ITM, see Load-line
effect compensation (on page 5-34).
2. Choose the maximum voltage for the selected source range. For example, many high power
transistors require fairly high voltages and currents, so the PMU 40 V source range is common.
3. Set the thresholds in the All Parameters pane (see next figure and PMU - all terminal parameters
(on page 6-70) for more detail). Enter the maximum voltage for the DUT. For a transistor, set the
ThresholdVoltDrain voltage for the maximum voltage for the drain.
