13: LPT library function reference Model 4200A-SCS Parameter Analyzer
13-202 4200A-901-01 Rev. C / February 2017
cviv_display_config
This command configures the LCD display on the 4200A-CVIV Multi-Switch.
Usage
int cviv_display_config(int instr_id, int channel, int identifier, char *value);
The instrument identification code of the 4200A-CVIV:
4200A-CVIV channel (use to set a terminal name): 1 to 4
4200A-CVIV virtual channel (use to set the test name): 5
Display the name of the terminal: KI_CVIV_TERMINAL_NAME or 1
Display the name of the test: KI_CVIV_TEST_NAME or 0
A string that defines the name (up to 16 characters for a test name or 6 characters
for a terminal name)
Details
Sets the name for the channel terminal or test that is displayed on the 4200A-CVIV for the selected
channel.
The channel and identifier settings must be set for either terminal or test name. For example, if
channel is set to 2, identifier must be set to KI_CVIV_TERMINAL_NAME.
If the clrcon command is sent, the 4200A-CVIV display is updated to show the change in
connections. If the 4200A-CVIV display is turned off, it remains off after a clrcon.
Example
cviv_display_config(CVIV1, 2, KI_CVIV_TERMINAL_NAME, "Source");
This command sets the name of the channel 2 terminal on the 4200A-CVIV display.
Also see
clrcon (on page 13-199)
cviv_config (on page 13-201)
cviv_display_power (on page 13-203)
