-SCS Parameter Analyzer Reference Manual Section 6:
4200A-901-01 Rev. C / February 2017 6-143
Configure a complex test
For more complex tests, you can:
• Set advanced test and terminal parameters.
• Set up multiple steps or sweeps to track simultaneously using masters and subordinates.
• Configure actions.
• Configure sites and subsites.
• Set up subsite cycling for stress and measure cycles.
Test and terminal settings
You can access test and terminal settings from the center and right panes of Clarius when Configure
is selected.
The most common terminal settings are available in the center pane when Key Parameters is
selected. Additional common test settings are available in the right Terminal Settings pane.
Less commonly used terminal settings are available in a dialog box that you open with the Advanced
button on the Terminal Settings pane.
To view all terminal settings, select All Parameters from the center pane. In this view, all terminal
settings are displayed for every terminal.
Test settings are also displayed in the right pane. Test settings affect all terminals in the selected test.
The most common settings are available in the right. Additional settings are available when you click
the Advanced button.
For descriptions of all the test and terminal settings, refer to Test and terminal setting descriptions
(on
page 6-22).
