Section

13: LPT library function reference Model 4200A-SCS Parameter Analyzer

Reference Manual

13-112 4200A-901-01 Rev. C / February 2017

pulse_measrt

This command returns pulse source and measure data in pseudo real-time.

Usage

int pulse_measrt(int instr_id, int chan, char *VMeasColName, char *IMeasColName,

char *TimeStampColName, char *StatusColName);

instr_id

The instrument identification code: PMU1, PMU2, and so on

chan

Channel number of the pulse card: 1 or 2

VMeasColName

Column name for V-measure data in the Clarius Analyze sheet

IMeasColName

Column name for I-measure data in the Clarius Analyze sheet

TimeStampColName

Column name for the time stamp data in the Clarius Analyze sheet

StatusColName

Column name for the status data in the Clarius Analyze sheet

Pulsers

4225-PMU

Pulse mode

Standard and Segment Arb

Details

Use this command to return and display test data in pseudo real-time. As measurements are

performed, the data is automatically placed in the Clarius Analyze sheet. This command is also used

to name the columns in the Clarius Analyze sheet.

This command must be called before calling pulse_exec to start the test.

The pulse_measrt command is not compatible with using KXCI to call user libraries remotely (see

Calling KULT user libraries remotely (on page 9-81). Use PostDataDouble for user test modules

(UTMs) that will be called using KXCI.

Example

pulse_measrt(PMU1, 1, "V-Measure", "I-Measure", "Timestamp", "Status");

This example configures channel 1 of PMU1 to return data in pseudo real-time.

Also see

pulse_exec (on page 13-98)

pulse_fetch (on page 13-101)
