Keithley 4200A-SCS Reference Manual

Section
13: LPT library function reference Model 4200A-SCS Parameter Analyzer
Reference Manual
13-8 4200A-901-01 Rev. C / February 2017
Command Description
rtfary (on page 13-84)
Returns the array of force values used during the subsequent voltage or
frequency sweep.
setauto (on page 13-180)
Selects the auto measure range.
setfreq (on page 13-181)
Sets the frequency for the AC drive.
setlevel (on page 13-182) Sets the AC drive voltage level.
setmode (4210-CVU) (on
page 13-182)
Sets operating modes specific to the 4210-CVU.
smeasf (on page 13-184)
Returns the frequencies used for a sweep.
smeasfRT (on page 13-185) Returns the sourced frequencies (in real time) for a sweep.
smeast (on page 13-186)
Returns timestamps referenced to sweep measurements or a system timer.
smeastRT (on page 13-187)
Returns timestamps (in real time) referenced to sweep measurements or a
system timer.
smeasv (on page 13-188)
Returns the DC bias voltages used for a sweep.
smeasvRT (on page 13-189)
Returns the sourced DC bias voltages (in real time) for a sweep.
smeasz (on page 13-189)
Performs impedance measurements for a sweep.
smeaszRT (on page 13-191)
Makes and returns impedance measurements for a voltage or frequency sweep
in real time.
sweepf (on page 13-192)
Performs a frequency sweep.
sweepv (on page 13-193)
Performs a linear staircase DC voltage sweep.
Switch commands
Command Description
addcon (on page 13-198)
Adds connections without clearing existing connections.
clrcon (on page 13-199)
Opens or de-energizes all device under test (DUT) pins and instrument matrix
relays, disconnecting all crosspoint connections.
conpin (on page 13-199)
Connects pins and instruments together.
conpth (on page 13-200)
Connects pins and instruments together using a specific pathway.
cviv_config (on page 13-
201)
Sends switching commands to the 4200A-CVIV Multi-Switch.
cviv_display_config (on
page 13-202)
Configures the LCD display on the 4200A-CVIV Multi-Switch.
cviv_display_power (on
page 13-203)
Sets the display state of the LCD display on the 4200A-CVIV.
delcon (on page 13-204)
Removes specific matrix connections.
devint (on page 13-13)
Resets all active instruments in the system to their default states.
