Supported external equipment
Keithley Instruments provides a number of standard user libraries to control external equipment that
is typically used in semiconductor characterization applications. Standard user-module libraries are
provided for the equipment shown in the table below.
Category Instrument User library Additional information
Switch matrix
1
Series 700 Switching System
Matrixulib
Using Switch Matrices (on page A-1)
Capacitance
meter
2
Keithley Instruments Model 590 CV
Analyzer
KI590ulib
Using a Model 590 CV Analyzer (on
page B-1)
Keithley Instruments Model 595
Quasistatic C-V Meter
KI595ulib
Model 595 Quasistatic C-V Meter
Instruction Manual (document number
595-901-01)
Keithley Instruments Model 82
Simultaneous C-V System
ki82ulib
Using a Keithley Model 82 C-V System
(on page D-1)
Keysight Technologies 4284 or 4980
LCR Meter
HP4284ulib
Using a Keysight 4284/4980A LCR
Meter (on page C-1)
Keysight Model 4294 LCZ Meter
HP4294ulib
HP4294ulib user library reference (on
page 6-310)
Pulse
generator
3
Keithley Instruments Model 3402
Pulse Generator
ki340xulib
Series 3400 Pulse Pattern Generators
User’s Manual (document number
3400S-900-01B)
Keysight Model 8110A Pulse
Generator
HP8110ulib
Using a Keysight 8110A/81111A Pulse
Generator (on page E-1)
Probe station
4
Karl Suss MicroTec Model PA-200
semiautomatic probe station
PRBGEN
Suss MicroTec PA-200 Prober (on page
G-1)
Micromanipulator Model 8860
semiautomatic probe station
PRBGEN
Micromanipulator 8860 Prober (on page
H-1)
Manual probe station and fake probe
station
PRBGEN
Using a Manual or Fake Prober (on page
I-1)
Cascade Summit-12000 probe station
PRBGEN
Cascade Summit-12000 Prober (on
page J-1)
Signatone CM500 Prober
PRBGEN
Signatone CM500 Prober (on page K-1)
Test fixture
Keithley Instruments Model LR:8028
Component Test Fixture
Not
applicable
Connections and Configuration (on page
2-1)
Keithley Instruments Model 8007
Semiconductor Test Fixture
Not
applicable
Connections and Configuration (on page
2-1)
Generic test fixture
Not
applicable
Connections and Configuration (on page
2-1)
