Section

13: LPT library function reference Model 4200A-SCS Parameter Analyzer

Reference Manual

13-18 4200A-901-01 Rev. C / February 2017

Instrument identification code Attribute name string Attribute value string

PRBR1

NUMOFPINS

MODELNUM

FAKE

CC12K

CM500

MANL

MM40

PA200

CVUx

MODELNUM

KICVU4210

VPUx

VPUxCH1

VPU

CH2

MODELNUM

KIVPU4220

PMUx

PMUxCH1

PMU

CH2

MODELNUM

KIPMU4225

CVIVx

MODELNUM

KICVIV

GNDU

MODELNUM

GNDU

Also see

None

getinstid

This command returns the instrument identifier (ID) from the instrument name string.

Usage

int getinstid(char *instr_name, int *instr_id);

instr_name

The instrument name string

instr_id

The instrument identification code

Also see

None

getinstname

This command returns the instrument name string from the instrument identifier (ID).

Usage

int getinstname(int *instr_id, char *inst_name);

instr_id

The instrument identification code

inst_name

The returned instrument name string

Also see

None
