SIN Formulator function

Returns the sine of each value in a designated column (vector) under Columns or any operand.

Usage

SIN(Value)

Value

The name of any column (vector) in the Data Series list or any operand

Details

Returns the value in radians.

Example

F1 = SIN(DRAINI)

Also see

None

TAN Formulator function

Returns the tangent of each value in a designated column (vector) under Columns or any operand.

Usage

TAN(Value)

Value

The name of any column (vector) in the Data Series list or any operand

Details

Returns the value in radians.

Example

F1 = TAN(DRAINI)

Also see

None
