Section

6: Clarius Model 4200A-SCS Parameter Analyzer

Reference Manual

6-234 4200A-901-01 Rev. C / February 2017

Trigonometry

The following Formulator functions provide trigonometric operations.

ACOS Formulator function

Returns the arc cosine of each value in a designated column (vector) under Columns or any operand.

Usage

ACOS(Value)

Value

The name of any column (vector) in the Data Series list or any operand

Details

Returns the value in radians.

Example

F1 = ACOS(DRAINI)

Also see

None

ASIN Formulator function

Returns the arc sine of each value in a designated column (vector) under Columns or any operand.

Usage

ASIN(Value)

Value

The name of any column (vector) in the Data Series list or any operand

Details

Returns the value in radians.

Example

F1 = ASIN(DRAINI)

Also see

None
