-SCS Parameter Analyzer Reference Manual Section 10:
KPulse (for Keithley Pulse Cards)
4200A-901-01 Rev. C / February 2017 10-13
4. Enable Channel 1 and/or Enable Channel 2. The loaded .kaf file consists of a waveform for
one or both of the channels. If the .kaf file was saved with one or both channels enabled, the
.kat tile loads into this tab with the same channels enabled. A channel must be enabled in order
to preview and output its waveform. The waveform for Channel 1 is blue and the waveform for
Channel 2 is red.
5. Configure triggers for both channels of the pulse card:
 Trigger Source - Software, External, or Internal Bus. With External enabled, select the
trigger source: Initial Falling, Initial Rising, Per Pulse Falling, or Per Pulse Rising.
 Output Mode - Select the output trigger mode: Continuous Mode or Burst Mode.
6. Configure the Channel 1 Settings and/or Channel 2 Settings. The Pulse Count field is active if
the Burst Mode is the selected trigger mode.
To configure other installed pulse cards for Custom File Arb, repeat steps 1 through 6.
7. Turn on all enabled channels - Select the green triangle to turn on enabled channels for all
installed pulse cards in the 4200A-SCS. With the output on, the square box turns red. Select the
red box to turn off the outputs of all pulse cards.
Waveform types
KPulse provides the following fundamental waveform types to use as the building blocks for custom
file arb:
• Sine waveform (on page 10-14)
• Square waveform (on page 10-14)
• Triangle waveform (on page 10-15)
• Custom waveform (on page 10-15)
• Calculation waveform (on page 10-17)
• Noise waveform (on page 10-17)
• Gaussian waveform (on page 10-18)
• Ramp waveform (on page 10-18)
• Sequences waveform (on page 10-19)
As explained in Custom Arb file operation: Select and configure waveforms (on page 10-10), a
waveform is created using the Waveform Generator. After selecting and configuring one of the above
waveform types, the waveform is placed into the Scratch Pad.
The period for the waveforms is determined by the Time Per Point setting in the Arb Generator tab
(refer to Custom Arb file operation: Copy waveforms into Sequencer (on page 10-11)).
