Keithley 4200A-SCS Reference Manual

Section
10: KPulse (for Keithley Pulse Cards) Model 4200A-SCS Parameter Analyzer
Reference Manual
10-18 4200A-901-01 Rev. C / February 2017
Gaussian waveform
An example of a Gaussian waveform is shown in the next figure. The waveform for this example is
named GAUSSIAN1, but can be any name that is not already used in the Scratch Pad.
After changing one or more settings, select Preview to display the waveform. Select OK to place the
waveform in the Scratch Pad.
Figure 485: Gaussian waveform
Ramp waveform
An example of a ramp waveform is shown in the next graphic. The waveform for this example is
named RAMP1, but can be any name that is not already used in the Scratch Pad.
After changing one or more settings, select Preview to display the waveform. Select OK to place the
waveform in the Scratch Pad.
Figure 486: Ramp waveform
