6: Clarius Model 4200A-SCS Parameter Analyzer
6-354 4200A-901-01 Rev. C / February 2017
7. Carefully insert the LEMO triaxial connector into the Force connector on the SMU in slot 4.
8. Route BNC cable from SMU4 to the DUT array WL2 terminal. If necessary, use a triaxial-to-BNC
adapter.
9. Connect the cable to the probe manipulator.
10. Connect the SMA of one of cable assemblies to CHANNEL 1 of the pulse card in the left-most
slot (the pulse card in the slot with the highest number).
11. Carefully insert the LEMO triaxial connector into the Force connector on the SMU in slot 3.
12. Route the BNC cable from SMU3 to the DUT array BL2 connection. If necessary, connect a
triaxial-to-BNC adapter.
13. Connect the cable to the probe manipulator.
14. Connect the SMA of one of the cable assemblies to CHANNEL 2 of the pulse card in the right-
most slot (the pulse card in the slot with the lowest number).
15. Carefully insert the LEMO triaxial connector into the Force connector on the SMU in slot 2.
16. Route the BNC cable from SMU2 to the DUT array WL2 connection. If necessary, connect a
triaxial-to-BNC adapter.
17. Connect the cable to the probe manipulator.
18. Connect the SMA of one of the cable assemblies to CHANNEL 1 of the pulse card in the right-
most slot (the pulse card in the slot with the lowest number).
19. Carefully insert the LEMO triaxial connector into the Force connector on the SMU in slot 1.
20. Route the BNC cable from SMU1 to the DUT array WL1 connection. If necessary, connect a
triaxial-to-BNC adapter.
21. Connect the cable to the probe manipulator.
Embedded computer policy
If you install software that is not part of the standard application software for the 4200A-SCS, the
non-standard software may be removed if the instrument is sent in for service. Back up the
applications and any data related to them before sending the instrument in for service.
Do not reinstall or upgrade the Microsoft
®
Windows
®
operating system (OS) on any 4200A-SCS. This
action should only be performed at an authorized Keithley Instruments service facility. Violation of
this precaution will void the 4200A-SCS warranty and may render the 4200A-SCS unusable. Any
attempt to reinstall or upgrade the operating system (other than a Windows service pack update) will
require a return-to-factory repair and will be treated as an out-of-warranty service, including time and
material charges.
Although you must not attempt to reinstall or upgrade the operating system, you can restore the hard
drive image (complete with the operating system) using the Acronis True Image OEM software tool,
described in System-level backup and restore software (on page 11-4).
