Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 9: Keithley External Control Interface (KXCI)
4200A-901-01 Rev. C / February 2017 9-45
ID
This command places the ID of the instrument in a particular buffer.
Usage
ID
Details
The instrument ID depends on whether you are in 4200A mode or whether you are in the 4145 mode.
Refer to the table below.
Hardware comparisons
Instrument type Keithley Instruments 4200A-SCS Keysight 4145B
Source measure units (SMUs)
2 to 9
4 (fixed)
Voltage monitor (VM)
You can configure any SMU to function as
a VM. Up to 9 VMs are possible.
2 (fixed)
Voltage source (VS)
You can configure any SMU to function as
a VS. Up to 9 VSs are possible.
2 (fixed)
Also see
None
DR
This command enables or disables service request for Data Ready.
Usage
DRA
A
Set service request for Data Ready:
• Disable service request for data ready: 0
•
Enable service request for data ready: 1
Details
The GPIB provides a status byte register to monitor instrument operation. Two bits of this register are
bit B0 (Data Ready) and bit B6 (RQS). After all programmed measurements are completed, the data
becomes ready for output and bit B0 (Data Ready) sets.
If service request for Data Ready is enabled, bit B6 (RQS) will also set when data is ready for output.
If service request for Data Ready is disabled, bit B6 will not set when data is ready.
Also see
None
