Keithley 4200A-SCS Reference Manual

Section
9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer
Reference Manual
9-40 4200A-901-01 Rev. C / February 2017
DV and DI
These commands set up each SMU channel.
Usage
AAB, CC, ±DDD.DDDD, ±EEE.EEEE
AA
Source mode:
• Voltage source: DV
• Current source:
DI
B
SMU channel: 1 to 9
CC
Voltage source range:
• Autorange: 0
• 20 V range: 1
• 200 V range: 2
• 200 V range: 3
• 200 mV range: 4 (only with a preamplifier)
• 2 V range: 5 (only with a preamplifier)
Current source range:
• Autorange: 0
• 1 nA range (only with a preamplifier): 1
• 10 nA range (only with a preamplifier): 2
• 100 nA range: 3
• 1 µA range: 4
• 10 µA range: 5
• 100 µA range: 6
• 1 mA range: 7
• 10 mA range: 8
• 100 mA range: 9
• 1 A range (only with a 4210-SMU): 10
• 1 pA range (only with a preamplifier): 11
• 10 pA range (only with a preamplifier): 12
•
100 pA range (only with a preamplifier): 13
DDD.DDDD
Output value:
• Volts: -210.00 to +210.00
• Amps, 4200-SMU: -0.1050 to +0.1050
•
Amps, 4210-SMU: -1.0500 to +1.0500
EEE.EEEE
Compliance value:
• Volts: -210.00 to 210.00
• Amps, 4200-SMU: -0.1050 to +0.1050
•
Amps, 4210-SMU: -1.0500 to +1.0500
