Keithley 4200A-SCS Reference Manual

Section
13: LPT library function reference Model 4200A-SCS Parameter Analyzer
Reference Manual
13-206 4200A-901-01 Rev. C / February 2017
The 4225-PMU or 4220-PGU returns to the following states:
• The pulse mode is maintained. For example, if the pulse card is in Segment Arb mode, it will still
be in Segment Arb mode after the devint process is complete.
• 5 V and 10 mA ranges
• If in pulse mode:
 Period of 1.0 µs
 Transition Times (Rise and Fall) of 100 ns
 Width of 500 ns
 Voltage high and low of 0 V
 Load of 50 Ω
• If in segmented arb mode, Start Voltage is 0 V
• If in arbitrary waveform mode, Table Length is 100
Also see
clrcon (on page 13-199)
clrscn (on page 13-9)
clrtrg (on page 13-11)
dev_abort (on page 13-92)
devclr (on page 13-67)
kibdefint (on page 13-24)
