Model 4200A
-SCS Parameter Analyzer Reference Manual Section 13:
LPT library function reference
4200A-901-01 Rev. C / February 2017 13-213
Code Status or error titles
-807
Function not supported by 4200-VPU.
-808
Solid state relay control values ignored for 4200-VPU.
-809
Time Per Point must be between %g and %g.
-810
Attempts to control VPU trigger output are ignored by the 4200-VPU.
-811
Measure range not valid for %s.
-812
WARNING: Sequence %d, segment %d. Cannot measure with PGUs/VPUs.
-820
PMU segment start value %gV at index %d does not match previous segment stop value of
%gV.
-821
PMU segment stop time (%g) greater than segment duration (%g)
-822
PMU sequence error for entry %d. Start value %gV does not match previous stop value of
%gV.
-823
Start and stop window was specified for PMU segment %d, but no measurement type was
set.
-824
Measurement type was specified for PMU segment %d, but start and stop window is
invalid.
-825
%s set to post to column %s. Cannot fetch data that was registered as real-time.
-826
Cannot execute PMU test. No channels defined.
-827
Invalid pulse timing parameters in PMU Pulse IV test.
-828
Maximum number of segments per PMU channel exceeded (%d).
-829
The sum of base and amplitude voltages (%gV) exceeds maximum (%gV) for present
range.
-830
Pulse waveform configuration exceeded output limits. Increase pulse period or reduce
amplitude or total time of pulsing.
-831
Maximum number of samples per channel (%d) exceeded for PMU%d-CH%d.
-832
Pulse slew rate is too low. Increase pulse amplitude or reduce pulse rise and fall time.
-833
Invalid trigger source for PIV test.
-834
Invalid pulse timing parameters.
-835
Using the specified sample rate of %g samples/s, the time (%g) for sequence %d is too
short for a measurement.
-836
WARNING: Sequence %d, segment %d is attempting to measure while solid state relay is
open. Disabling measurement.
-837
No RPM connected to channel %d of PMU in slot %d.
-838
Timing parameters specify a pulse that is too short for a measurement using %g samples/s.
-839
Timing parameters contain measurement segments that are too short to measure using %g
samples/s.
-840
SSR cannot be opened when using RPM ranges. Please change SSR array to enable relay
or select PMU measure range.
-841
WARNING: SSR is open on segment immediately preceding sequence %d. Measurement
will be invalid for 25 µs while relay settles.
-842
This test has exceeded the system power limit by %g watts.
-843
Step size of %g is not evenly divisible by 10 ns.
-844
Invalid combination of start %g1, stop %g2 and step %g3.
-845
No pulse sweeper was configured - Test will not run.
-846
Maximum Source Voltage Reached: Requested voltage across DUT resistance exceeds
maximum voltage available.
-847
Output was not configured - Test will not run.
-848
Sweep step count mismatch for the sweeping channels. All sweeping channels must have
same # of steps.
