A: Using switch matrices Model 4200A-SCS Parameter Analyzer
A-22 4200A-901-01 Rev. C / February 2017
The next figure shows the remote sense signal paths for the Keysight Model 4980A LCR meter
through a 2-pole matrix card. Since row pairing is required, the remote sense setting must be used.
Figure 538: Keysight Model 4980A signal paths through a two-pole matrix card using remote
sensing
