Appendix

B: Using a Model 590 C-V Analyzer Model 4200A-SCS Parameter Analyzer

Reference Manual

B-26 4200A-901-01 Rev. C / February 2017

Procedure

1. You are prompted to open the circuit so that an offset capacitance measurement can be made if

needed.

2. If a cable compensation file is specified, the compensation information in that file for the selected

range and frequency is loaded. If not, instrument default compensation is used.

3. A C-V pulse sweep is done.

Also see

None
